The LX25 LED Corded Primary Light brings a new level of brightness to the LX family of lights. Utilizing the latest in microprocessor technology along with the CREE XM-L2 Cool White LED chip and a new reflector, the LX25 combines maximum brightness with maximum efficiency. With 30,000 LUX at approximately 6,500 Kelvin, the LX25’s brightness out does most other corded primary lights on the market today.
The LX25’s 6-degree concentrated light beam, reflecting off a polished metal reflector, punches through the water lighting the way with a clean center spot. Lighting your way through the darkness has never been so bright. Its compact design and provided quick release soft hand mount make it ideal for any type of diving requiring a good light source as well as traveling where weight matters.
Built around the XM-L2 Cool White LED chip that maximizes output and efficiency, the LX25 has three modes; high power, low power, and strobe. Using our NiMH Slimline battery, the LX25 burns for 3.5 hours on high power, eight hours on low power, and 36 hours in strobe mode. Making sure each light meets the high standards it was designed under, every light is individually tested and the average LUX is measured at one meter using a Konica Minolta Chroma Meter.
An integrated microprocessor control unit monitors battery voltage to keep the light operating at its peak efficiency. As battery voltage drops, light output steps down eliminating the possibility of suddenly being left in the dark due to a dead battery. The light alerts the diver of this step down in light output by a series of flashes, after which, the light produces another 1.5 hours of usable light. The Slimline nickel metal hydride battery with included Smart Charger does not contain lithium, and is not subjected to TSA travel restrictions.
Activated using a rotary switch on the light head, the LX25 allows divers the ability to mount the battery canister anywhere on their equipment configuration, eliminating the need to be able to reach the canister to activate a switch.
With a 500-foot (152 m) depth rating and no switch boot on the canister, the LX25 excels under all the rigors of diving providing proven protection against flooding.
Providing reliability, durability, and a light output brightness few other lights can boast, the LX25 is the next generation of technology-driven LED lights that will take your diving to new levels whether exploring caves, penetrating wrecks, or night diving on a reef.
NOTE: Do NOT plug the battery into the light head while the battery is not in the canister. Even with the light off, plugging the light in backwards with the polarity reversed can damage the light. Always use a fresh, properly charged battery to achieve rated burn times.
TECHNICAL DETAILS
- Light output: 30,000 LUX
- Beam angle: 6-degree spot
- Light color temperature: Approximately 6500 Kelvin
- Battery: 12v (nominal) 4500ma NiMH Slimline battery pack. (Does not fall under TSA travel restrictions.)
- Burn time
o High power: 3.5 hours at 30,000 LUX
o Low power: 8 hours at 13,000 LUX
o Strobe: 36 hours at 20,000 LUX
- 5 hour burn time after light output step down from full power
- Strobe cycle time: 100ms on then 900ms off
- Mount:
o Light head: Quick release soft hand mount
o Canister: Quick belt mount
- Activation: Rotary magnetic on/off switch
- Size:
o Light head: 2.7 in. (6.85cm) length, 2 in. (5.0cm) diameter
o Canister: 9 in. (22.88cm) height, 2.6 in. (6.6cm) diameter
- Weight: 3.8 lbs. (1.72kg)
- Buoyancy: 1.25 lbs. (0.56kg) negative in water
- Depth rating: 500 feet (152m)
- LED chip: CREE XM-L2 Cool White
- Smart Charger:
o Input voltage: Automatically adjusts to 110/220 volts AC and 50/60Hz frequency
o Indicators: Red and green LED
o Plugs: Two-prong banana plug
o Charging time: Up to 6 hours from complete discharge
- Compliance: RoHS compliant
- Made in the USA
